The Perytons™ Anywhere Add-On enables capturing data from remote locations using an IP connected remote gateway:
Figure 376 – Perytons™ Anywhere Add-On (with cellular modem)
The gateway is based on a RaspberryPi
HW platform and is used for capturing 2.4GHz or Sub-1-GHz (depending on the
dongle used) 802.15.4 based data from remote locations. It is controlled by the
Perytons™ Protocol Analyzer software in a similar way as when the SW connects to
a locally connected USB front-end including features like noise-measurement,
etc. The gateway requires connection to a broadband WAN (Wide Area Network)
through which the captured data is communicated to and from the Perytons™
Protocol Analyzer application.
Different gateway options are compatible with
the Perytons™ Protocol Analyzer – e.g.:Ethernet, WiFi, 3GCellular.
When purchasing the Perytons™ Anywhere Add-On and activating the license accordingly, relevant options in the application become available.
